The Bubble Tea Filling and Sealing Machine is an automatic cup filling and sealing machine designed for high-efficiency cup packaging of boba milk tea, fruit tea, and other beverages,which designed for factory and OEM beverage production environments. It integrates cup dropping, precise liquid filling, heat sealing, and cup ejection into a single continuous workflow, enabling efficient and hygienic cup packaging for bubble milk tea, fruit tea, and other cup-based beverages.
Engineered with food-grade SUS 304 stainless steel and a PLC + HMI control system, this machine delivers stable performance and consistent sealing quality. It supports multiple cup materials and sealing film formats, making it suitable for OEM drink production lines, central kitchens, and export-oriented beverage packaging operations.
Fully Automatic Operation
Integrates cup dropping, liquid filling, film sealing, and cup ejection in one continuous process.
High Efficiency
Supports high-speed filling and sealing – up to XX cups per minute (customizable based on model).
Accurate Filling System
Equipped with piston pump or flow meter for precise liquid dosing with minimal waste.
Adaptable Cup Sizes
Compatible with various cup diameters (e.g., 75mm–95mm), heights, and materials (PP, PET, paper).
Secure Heat Sealing
Ensures leak-proof and tamper-evident seals using roll film or pre-cut lids.
Touchscreen Control Panel (PLC + HMI)
User-friendly interface for setting parameters, diagnostics, and real-time monitoring.
Food-Grade Construction
Built with SUS 304 stainless steel for hygiene and easy cleaning; compliant with CE/FDA standards.
Optional Add-ons
Nitrogen flushing, date coding, syrup injection, straw-inserting system, and cup detection sensors.
Compact Footprint
Space-saving design suitable for small to medium-sized production areas.
Reliable Performance
Designed for stable 24/7 operation in commercial environments like tea shops and beverage factories.
| Item | Details |
|---|---|
| Model | YJN-FSB-6 |
| Filling Range | 50–500 ml (adjustable) |
| Filling Accuracy | ±1–2% |
| Cup Diameter | 75–95 mm (custom sizes available) |
| Cup Material | PP, PET, PS, Paper |
| Sealing Film Type | Roll film / Pre-cut foil lids |
| Sealing Method | Heat sealing |
| Production Capacity | Up to 4800 cups/min (depends on cup size & volume) |
| Control System | PLC + HMI touchscreen |
| Power Supply | 220V/380V, 50/60Hz |
| Power Consumption | 3 kW |
| Air Pressure Requirement | 0.6–0.8 MPa |
| Machine Dimensions | 6400 × 1200 × 2100 mm |
| Net Weight | 2000 kg |
| Material of Construction | SUS 304 Stainless Steel |
| Optional Functions | Nitrogen flushing, Date printer, Straw inserter |
The Bubble Tea Filling and Sealing Machine is widely used in various beverage packaging settings. Ideal for both small shops and industrial-scale production, it ensures fast, clean, and consistent sealing of cups.
Bubble Tea Shops / Boba Chains
Efficiently fills and seals milk tea, fruit tea, and specialty drinks during peak hours.
Central Kitchen & Beverage Factories
Supports large-volume drink production with stable, automated performance.
Bottling & OEM Co-Packers
Ideal for contract packaging of branded drinks in sealed cups for supermarkets or delivery.
Food Courts & Kiosks
Space-saving design makes it suitable for small foodservice outlets with cup-based beverages.
Convenience Beverage Production
Used to package ready-to-drink boba teas, puddings, yogurt drinks, and herbal teas for retail distribution.
Export Packaging Solutions
Meets hygiene and safety standards (CE/FDA), suitable for global beverage markets.
We understand that every production line has unique needs. Our Bubble Tea Filling and Sealing Machines offer a wide range of customization capabilities to help you create the perfect packaging solution:
Customized Output Capacity
Machines can be tailored for different production scales — from low-speed models for startup tea shops to high-speed, multi-lane systems for industrial factories. Output can be configured up to 200 cups/min depending on your needs.
Flexible Packaging Configurations
Supports a wide range of cup types, shapes, and sealing styles — including round/rectangular cups, PP/PET/paper materials, and sealing with roll film or pre-cut lids. Packaging style and mold design can be customized for your brand.
Adjustable Filling Volume
Filling systems are customizable to handle various liquid volumes, from small 50 ml servings to larger 500 ml cups. Precision piston or flowmeter-based systems ensure accurate filling for different beverage viscosities.
Additionally, we offer process customization based on your beverage formula, packaging workflow, and regional compliance standards.
The machine supports a wide range of cup packaging configurations to accommodate different OEM product specifications:
Compatible with PP, PET, PS, and paper cups
Standard cup diameter range from 75 mm to 95 mm
Custom cup sizes supported based on production requirements
Sealing options include roll film and pre-cut foil lids
This adaptability allows OEM producers to manage multiple cup formats and packaging styles within a single automated solution.
What types of beverages can this machine handle?
The machine is designed for bubble milk tea, fruit tea, and other liquid beverages commonly used in cup-based packaging applications.
What cup materials and sizes are supported?
It supports PP, PET, PS, and paper cups with standard diameters from 75 mm to 95 mm. Custom cup sizes are available.
Does the machine support different sealing films?
Yes. Both roll film and pre-cut foil lids are supported.
Is the machine suitable for continuous OEM production?
The fully automatic workflow and PLC + HMI control system support stable operation in factory and OEM production environments.
How accurate is the filling system?
The filling accuracy is ±1–2% within the adjustable filling range of 50–500 ml.
Can one machine handle multiple cup sizes and product specifications?
Cup size, filling volume, and sealing parameters can be adjusted to support different OEM product requirements.
What customization options are available?
Customization includes output capacity configuration, cup size and mold design, filling volume adjustment, sealing format, and optional functional modules.
To confirm cup compatibility, filling range, and production configuration for your OEM project, please contact us to request technical details or a customized configuration proposal for the Bobble Tea Cup Filling and Sealing Machine.
